Specification
Features
- Equipped with 4-core ARM architecture
A55 processor - Wide voltage and temperature working
performance - Support 802.11a/b/g/n/ac protocol, dual
Wi-Fi antennas - 10.1-inch flat capacitive touch panel is
impact-resistant - Rich interfaces, including multiple
USB/RS232/LAN/HDMI and other I/O ports - Designed with a mini PCIe slot for
communication module or SSD expansion
| Durability | Front Panel IP65 compliant 8kV contact discharge, ±15kV air discharge |
| Operating System | Android 12 |
| Processor | RK3568 (up to 2.0GHz,4 cores) |
| Graphics | Mali-G52-2EE |
| Memory | 4GB LPDDR4x on board |
| Storage | 64GB eMMC |
| Display | 10.1", HD (800x1280), 700 Nits 10 point capacitive touch screen |
| Audio | Optional 2W speaker |
| Keyboard & Input | Power key x1 |
| Network & Connectivity | Intel® Wi-Fi 5 RTL8822CS (802.11 ac) Bluetooth® V5.0 Optional 4G LTE LTE-FDD: B1/3/5/7/8/20 LTE-TDD: B40 WCDMA: B1/5/8 GSM: 900/1800 China (China Unicom, China Telecom, China Mobile), Europe, Middle East, Africa, Taiwan, Japan |
| 1/O Interface | Micro SD card x 1 SIM card x 1 USB3.0 (typeA) x 1 USB3.0 OTG (typeA) x 1 USB2.0 (typeA) x 2 3.5mm AudioJack x 1 HDMI 2.0 typeA x 1 10/100/1000 Ethernet (RJ45) x 1 Serial port (RS232: D-sub, 9-pin) x 2 Optional RS232x1/RS485x1 DC5.5mmIn -jack x 1 (support 12-24V) SMA x 2 |
| Battery & Charging | 100-240V, 50Hz-60Hz, 48W Separated 3V/220mAh RTC |
| Environment | Operating temperature: -20°C to 60°C (-4°F-140°F) Storage tmperature: -30°C to 70°C (-22°F~158°F) Humidity: 95% Non-Condensing |
| Dimension | 257.2 mm (L) x 170 mm (W) x 45.95 mm (H) |
| Weight | 1.2 kg |
| Accessories | Standard: Adapter, Hook Assembly, Antenna |
| Warranty | One-year limited warranty standard |
