Specification
| Specification | |
|---|---|
| CPU | Intel Alder Lake i5-1235U/i7-1255U |
| Graphics | Intel® Iris® Xe Graphics eligible |
| OS | Windows 11 Pro 64bit no key |
| LCD | 14" 16:9 1920(H)×1080(V) FHD,1000cd/㎡ |
| RAM | 2 x DDR5 SO-DIMM, up to 64GB |
| Storage | 1 x M.2 2280 M-KEY, support NVMe SSD Additional 1 x M.2 M-KEY via expansion bay |
| Wi-Fi | WiFi 6 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax |
| 5G and LTE | Optional |
| Camera | 5.0MP |
| BT | BT5.1 (BLE) |
| Battery | Main battery: 4700mah/11.4V (53.58WH) Bridge battery: 1300mah/11.1V（14.4WH） |
| Speaker | Built-in 4Ω/3W x2 |
| GNSS | U-blox NEO-7,support: GPS or GLONASS |
| Fingerprint | x1 SPI fingerprint(power on login) |
| TPM | Built-in TPM2.0 SLB9670VQ2.0 |
| I/O connectors | USB3.2 x1, USB3.0 x1, USB2.0 x1, Thunderbolt 4 x1 |
| ∮3.5mm earphone jack x1 | |
| HDMI x1 | |
| TF card slot x1 | |
| SIM card slot x1 | |
| DC 19V 3.78A jack x1 | |
| DB9 (RS232) x1 | |
| (10/100/1000Mbps) RJ45 LAN x2 | |
| 12PIN Pogo PIN x1 (USB signal for customization) | |
| Expansion bay | 1 x M.2 2280 M-KEY 1 x M.2 E-KEY |
| Default accessories: Power adatper, AC cord | |
| Optional parts | |
| TP | Capacitive touch screen (by project) |
| AR FILM | Anti reflection film (by project) |
| OS Key | Windows 11 Home |
| Windows 11 Pro | |
| Windows 11 IOT Enterprise (i5) | |
| Windows 11 IOT Enterprise (i7) | |
| SSD Upgrade | 256G to 512G |
| 256G to 1T | |
| 4G LTE module | LTE-FDD: B1/3/5/7/8/20 LTE-TDD: B40 WCDMA: B1/5/8 GSM: 900/1800 |
| 5G module | 5G NR：n1/n2/n3/n5/n7/n8/n12/n20/ n25/n28/n38/n40/n41/n48*/ n66/n71/n77/n78/n79 LTE-FDD：B1/B2/B3/B4/B5/B7/B8/ B12(B17)/B13/B14/B18/B19/ B20/B25/B26/B28/B29/B30/ B32/B66/B71 LTE-TDD：B34/B38/B39/B40/B41/B42/ B43/B48 LAA：B46（only support 2 x 2 MIMO） WCDMA：B1/B2/B3/B4/B5/B6/B8/B19 |
| NFC | NXP300 |
| Optional Accsessory | |
| Additional Adaptor | 100~240V input 19V 3.78A/71.82W output |
| Additional Battery | 4700mah/11.4V (53.58WH) |
| 4-bay battery charger | MDC14 |
